PRIME TRINOCULAR MICROSCOPE
AJKANT Overseas manufactures premium international-grade PRIME TRINOCULAR MICROSCOPE designed for high-performance laboratory applications.
Technical Specifications & Models
| Model No PT-ULTRA | |
|---|---|
| Trinocular Observation Head | - Siedentopf Observation head inclined at 30° rotatable at 360° - Diopter adjustment ring on ocular tube (±5) - Inter-pupillary distance from 55mm to 75mm |
| Eyepiece (Anti fungus coated) | Wide Field 10X (Paired) F.O.V 18mm |
| Eyepieces | EWF Eyepiece Huygenian 10x (Paired) FOV 20mm |
| Objectives (Anti fungus coated) | S-Plan Achromatic 4X, 10X, 40X(S.L.), 100X Oil(S.L.) |
| Mechanical Stage | Double plate mechanical stage size 140mmX155mm having low positioned co-axial controls on ball bearing with Cross movement of 55mm X 75mm |
| Focusing System | - Co-axial focusing system with Pre-focusing Lever & Tension Adjustment Ring - The slow motion has 1Div=0.002mm - Quadruple nosepiece revolves on ball bearing |
| Sub Stage Condenser | Abbe condenser N.A.1.25 swing out filter holder, iris diaphragm |
| Illumination System | Built-in-base illumination system with 3W LED bulb and adjustable brightness |
| Standard Accessories | Operating manual, dust cover, guarantee card and Styrofoam molded pack |
| Optional Accessories | Digital Camera, Phase Contrast |
Need Bulk Export Pricing or Tender Quote?
We manufacture and export custom-configured laboratory setups with ISO 9001:2015 certification and seaworthy packaging.
Request B2B Export QuoteFrequently Asked Questions
Yes, the PRIME TRINOCULAR MICROSCOPE is manufactured by AJKANT Overseas under ISO 9001:2015 certified quality systems and carries CE declaration of conformity for global institutional export.
Standard units operate on AC 220V–240V / 50Hz. For North American and international export orders requiring 110V–120V / 60Hz power, custom configurations are available upon request.
Every PRIME TRINOCULAR MICROSCOPE is wrapped in shockproof bubble insulation, moisture-absorbing silica pouches, heat-sealed polythene vapor barriers, and secured inside ISPM-15 fumigated seaworthy wooden crates.
AJKANT Overseas provides a 1-year comprehensive standard warranty on the PRIME TRINOCULAR MICROSCOPE. Factory replacement parts, heating elements, sensors, and technical guidance are readily supplied.
The listed price serves as a B2B market benchmark. For customized specifications, university project discounts, or tender paperwork, click 'Request B2B Export Quote' or contact export@ajkantoverseas.com.
