Trinocular Research Microscope (TM-SIGMA Series)
ISO 9001:2015 certified Trinocular Research Microscope (TM-SIGMA Series) manufactured and exported by AJKANT Overseas.
Salient Features
- TM-SIGMA SERIES
- Model No
- Mechanical Body
- Single mold sturdy stand with anti rust materials. Extended base for better
- stability
Technical Specifications & Models
| Model No | TM- SIGMA |
|---|---|
| Mechanical Body | Single mold sturdy stand with anti rust materials. Extended base for better stability |
| Observation Heads | - Siedentopf Trinocular 30o inclined, 360 o Interpupillary distance adjustable between 55-75mm - Diopter adjustment ring on ocular tube (+5) - Vetical Phototube for micro photography |
| Eyepieces | WF Eyepiece 10x (Paired) FOV 18mm |
| Nosepiece | - Reverse angle quadruple nosepiece revolves on ball bearing with positive indexing - Soft rubber knurled grip on nosepiece |
| Objectives | Infinity Plan achromatic 4x,10x, 40x (SL),100x (SL) oil |
| - Mechanical stage Size 140mmx132mm, supported on ball bearing guide | |
| Stage | ways and having low positioned co-axial controls for stage movement - Cross movement 76mmX 50mm |
| Focusing | - Co-axial focusing control with ball bearing guide ways & large knobs, pre focusing lever & tension adjustment ring - The slow motion has 1DIV=0.002mm |
| Condenser | - Sub stage abbe condenser NA 1. 25 having a spherical lens - Adjustable iris diaphragm and swing out filter holder |
| Illumination | - The built-in-base illumination system with ultra high brightness single 3W LED cold light source - Brightness control knob |
| Standard Accessories | Dust cover, Operating Manual, Guarantee card, Styrofoam molded pack |
| Packaging Contents | Blue filter, Styron Foam Molded pack |
Need Bulk Export Pricing or Tender Quote?
We manufacture and export custom-configured laboratory setups with ISO 9001:2015 certification and seaworthy packaging.
Request B2B Export QuoteFrequently Asked Questions
Yes, the Trinocular Research Microscope is manufactured by AJKANT Overseas under ISO 9001:2015 certified quality systems and carries CE declaration of conformity for global institutional export.
Standard units operate on AC 220V–240V / 50Hz. For North American and international export orders requiring 110V–120V / 60Hz power, custom configurations are available upon request.
Every Trinocular Research Microscope is wrapped in shockproof bubble insulation, moisture-absorbing silica pouches, heat-sealed polythene vapor barriers, and secured inside ISPM-15 fumigated seaworthy wooden crates.
AJKANT Overseas provides a 1-year comprehensive standard warranty on the Trinocular Research Microscope. Factory replacement parts, heating elements, sensors, and technical guidance are readily supplied.
The listed price serves as a B2B market benchmark. For customized specifications, university project discounts, or tender paperwork, click 'Request B2B Export Quote' or contact export@ajkantoverseas.com.
