Product Overview & Key Applications
Optical System: Finite System Stand: Aluminium die-cast stand (anti-rust body) Viewing Head: Monocular, tube length 160mm 90° inclined head Adjustable rubber eye guards for comfortable viewing Eyepieces: Wide Field 10x, F.O.V. 16mm Antifungal and anti-reflection coated Nosepiece: Forward triple revolving nosepiece Click-stop mechanism with rubber grip Magnification: 100x to 1000x Objectives: Achromatic 10x/0.25 Achromatic 40x/0.65 (SL) Achromatic 100x/1.25 Oil (SL) Mechanical Stage: Single plate stage: 140mm × 140mm X/Y travel range: 70mm × 50mm High-quality stainless steel stage clips for slide holding Focusing: Vertical movement of the observation tube Coarse adjustment: rack & pinion mechanism Fine adjustment: screw lever mechanism Condenser: Movable Abbe condenser, N.A. 1.25 Antifungal, anti-reflection, aspheric lens Iris diaphragm Swing-in/out filter holder with frosted white/blue filter Illumination: Plano-concave mirror or 1W LED light (up to 20,000 working hours) Packaging: Inner thermocol/styrofoam packing Outer cardboard box
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is MEDICAL STUDENT MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
