Product Overview & Key Applications
Optical System: Infinity optical system. Stand: Single-mould, sturdy aluminium die-cast stand with anti-rust protection. Viewing Head: Siedentopf trinocular head, 30° inclined, 360° rotatable; interpupillary distance (IPD) 48–75 mm with diopter adjustment. Eye Guards: Adjustable rubber eye guards for comfortable viewing. Eyepieces: Wide-field 10x eyepieces, F.O.V 20 mm, with diopter adjustment; antifungal and anti-reflective coated. Nosepiece: Inward-facing quadruple revolving nosepiece with coded feature and click-stop mechanism. Objectives: Infinity plan achromatic objectives – 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 oil (SL). Mechanical Stage: Double-plate stage (180 mm × 130 mm) with vernier calibrations, specimen holder, and travel range of 74 mm × 30 mm. Focusing: Coaxial coarse and fine focusing, fine adjustment scale value 0.002 mm. Condenser: Fixed Abbe condenser, N.A. 1.25 with iris diaphragm; frosted white filter, antifungal and anti-reflective coated. Illumination: 3.5 W LED (up to 100,000 hours) with intensity control. Display: LCD screen showing magnification, sleep mode, brightness indication, lock, and other features. Power Supply: Universal 110–240 V with integrated voltage stabilizer. Packaging: Inner thermocol/styrofoam with outer cardboard box for safe handling.
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is Research Trinocular Microscope with Coded Display compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
