Product Overview & Key Applications
Viewing Head: Compensation-free binocular or trinocular head, inclined at 30° with adjustable interpupillary distance (48–75 mm). Eyepiece: Wide-field 10x/22 mm with diopter adjustment. Objectives: Infinite flat-field plan achromatic objectives – 4x/0.10, 10x/0.25, 40x/0.65, 100x/1.25 oil. Mechanical Stage: Double-layer stage measuring 140 mm × 120 mm with X/Y travel of 80 mm × 50 mm. Condenser: Abbe condenser, N.A. 1.25 with aspheric lens; iris diaphragm with frosted white filter; antifungal and anti-reflection coated. Focusing: Coaxial coarse and fine focusing with smooth gear mechanism; fine adjustment scale 0.002 mm. Illumination: LED light source, 5 W, DC 12 V 2A, with adjustable intensity control. Optional Accessories: WF 20x eyepiece; infinite plan objectives 20x, 60x; microscopic cameras; wooden storage box; pointers and reticules; phase contrast, dark field, fluorescence attachments.
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is PLATINUM RESEARCH TRINOCULAR MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
