ROTARY MICROTOME - SPENCER TYPE
Spencer Microtome is manually operated microtome, used to produce thin section of specimen of different hardness in both routine and research applications in Laboratory, Pathology and Histopathology, Biology, Medicines & Institutes. The instrument ensures lifelong smooth operations. Individual components are fabricated and assembled from selected material using latest technology. Ball and Flange object clamp provides flexible orientation of object piece. latest cam system eliminates the conventional cord system for feeding, resulting in better section cutting and improved efficiency of the machine.
Salient Features
- Precise sectioning of tissues upto 1 micron
- Front located feed indicator system
- Knife made of Imported fine grain steel alloy
- Convenient specimen holder
- Technical Specifications:
Technical Specifications & Models
| Model No. AJK-SPENCE-1 | |
|---|---|
| Section thickness range | 0-5 microns to 99 Microns |
| Section thickness settings | from 0.5 um - 1um in 0.5 um increment & from 1-99 microns in 1 micron increment |
| Specimen Orientation | X-axis and Y-axis : universal 8°, Z-axis: up to 360° |
| Vertical Specimen Feed | Approx 70mm |
| Horizontal specimen Feed | Approx 30mm |
| Maximum Specimen Size | 50 X 60 X 40mm |
| Sectioning Mode | Manunal |
| Mechanism | Equipped With enclosed micrometer & quick Lock Mechanism |
| Certification | ISO & CE Certified |
| Accessories | 1 Bottle of Lubrication Oil, 1 Knife 120mm long, Rexine Cover, Disposable Blade |
| Dimensions | Holder 500 x 380 x 305 mm 37 kgs (Approx) |
| Weight | - |
Need Bulk Export Pricing or Tender Quote?
We manufacture and export custom-configured laboratory setups with ISO 9001:2015 certification and seaworthy packaging.
Request B2B Export QuoteFrequently Asked Questions
Yes, the ROTARY MICROTOME - SPENCER TYPE is manufactured by AJKANT Overseas under ISO 9001:2015 certified quality systems and carries CE declaration of conformity for global institutional export.
Standard units operate on AC 220V–240V / 50Hz. For North American and international export orders requiring 110V–120V / 60Hz power, custom configurations are available upon request.
Every ROTARY MICROTOME - SPENCER TYPE is wrapped in shockproof bubble insulation, moisture-absorbing silica pouches, heat-sealed polythene vapor barriers, and secured inside ISPM-15 fumigated seaworthy wooden crates.
AJKANT Overseas provides a 1-year comprehensive standard warranty on the ROTARY MICROTOME - SPENCER TYPE. Factory replacement parts, heating elements, sensors, and technical guidance are readily supplied.
The listed price serves as a B2B market benchmark. For customized specifications, university project discounts, or tender paperwork, click 'Request B2B Export Quote' or contact export@ajkantoverseas.com.
