TRINOCULAR INDUSTRIAL
AJKANT Overseas manufactures premium international-grade TRINOCULAR INDUSTRIAL designed for high-performance laboratory applications.
Technical Specifications & Models
| Model No TRINO-S | |
|---|---|
| Trinocular Observation Head | - Siedentopf observation head inclined at 30° rotatable at 360° - Vertical phototube for micro photography - Diopter adjustment ring on ocular tube (±5) - Interpupillary distance from 55mm to 75mm |
| Eyepiece | Wide field eyepiece 10X (paired) F.O.V. 22mm |
| Objectives | BDM Long working distance plan 5X, 10X, 20X, 50X (SL), 100X (Dry) |
| Dark/Bright Field | BDM Long working distance plan 5X, 10X, 20X, 50X (S |
| Mechanical Body (Pre-Focusing) | - Co-axial focusing system with large knobs - Pre-focusing Lever & Tension Adjustment Ring - Quintuple nosepiece on ball bearing - Mechanical stage is 180mm X 140mm and Moving range is 30mm x 30mm - Mechanical stage has co-axial controls on ball bearing guide ways |
| Illuminator | The Epi illuminator has 12V-50W halogen lamp with v |
| Polarizing Outfit | - The Polarizer and Analyzer can be slide/out of the optical path - Analyzer rotatable at 360° |
| Standard Accessories | - 12V/50W halogen tungsten bulb - Operating manual - Dust cover - Guarantee card and Styrofoam molded pack |
| Optional Accessories | (Differential Interference Contrast DIC Filter 5X, 10X, 20X, 50X, 100X) |
Need Bulk Export Pricing or Tender Quote?
We manufacture and export custom-configured laboratory setups with ISO 9001:2015 certification and seaworthy packaging.
Request B2B Export QuoteFrequently Asked Questions
Yes, the TRINOCULAR INDUSTRIAL is manufactured by AJKANT Overseas under ISO 9001:2015 certified quality systems and carries CE declaration of conformity for global institutional export.
Standard units operate on AC 220V–240V / 50Hz. For North American and international export orders requiring 110V–120V / 60Hz power, custom configurations are available upon request.
Every TRINOCULAR INDUSTRIAL is wrapped in shockproof bubble insulation, moisture-absorbing silica pouches, heat-sealed polythene vapor barriers, and secured inside ISPM-15 fumigated seaworthy wooden crates.
AJKANT Overseas provides a 1-year comprehensive standard warranty on the TRINOCULAR INDUSTRIAL. Factory replacement parts, heating elements, sensors, and technical guidance are readily supplied.
The listed price serves as a B2B market benchmark. For customized specifications, university project discounts, or tender paperwork, click 'Request B2B Export Quote' or contact export@ajkantoverseas.com.
