Product Overview & Key Applications
Key Features Display: 12.2″ TFT, IPS Touch Screen, 360˚ Rotatable Camera: Built-in ULTRACAM, 5.0 MP Resolution Software: Pre-loaded Capture & Measurement Software Connectivity: Bluetooth 4.0 Battery: Li-ion, Up to 8 Hours Backup Operating System: Windows 10 Home Memory: 4GB RAM, 64GB eMMC + 64GB microSD Card I/O Ports: USB 3.0 × 1, Mini-HDMI × 1, microSD Slot × 1 Technical Specifications Optical System: High-contrast finite colour-corrected Optical System Magnification: 40x – 1000x Visual Magnification Stand: Aluminum Die-cast Stand with Hand Rests for Comfort & Stability Observation Head: Sidentopf Trinocular Head, 30° Inclined, 360° Rotatable, Interpupillary Distance 50–75mm, Dual Dioptric Adjustment Eyepieces: Widefield 10x/18mm, Anti-fungal & Anti-reflection, Hard Coated Nosepiece: Reverse Angle Quadruple Nosepiece (Ball Bearing Type) with Precise Click Stops Objectives: QUSP Series High-contrast Flat-field DIN PLAN Achromatic Objectives 4x 10x 40x (Spring-loaded) 100x (Spring-loaded, Oil Immersion) All antifungal & anti-reflection hard coated Mechanical Stage: Rackless X-axis, Double Plate Stage (190 × 140mm), X/Y Travel 90 × 65mm, Low Drive Right-hand Controls, Scratch-resistant Hard Coated Surface, Double Specimen Holder Clip Condenser: Sub-stage Abbe Condenser NA 1.25 with Iris Diaphragm, Frosted White/Blue Filter, Antifungal & Anti-reflection Coated, Rack & Pinion Movement on Stainless Steel Guides Focusing Control: Co-axial Coarse & Fine Focusing on Precision Gear System, Fine Adjustment 0.2mm/rotation, Max. 2 Micron Scale Increment Illumination: Halogen 6V–20W (up to 2,000 hrs life) LED 3W (up to 100,000 hrs life) Both with Variable Illumination Control Electronics: Universal Input 100V–240V AC, 50/60Hz, Built-in Voltage Stabilizer Package Contents: Power Cable (5ft), Immersion Oil, Spare Bulb (Halogen only), Nylon Dust Cover, Cleaning Cloth Optional Accessories Pointers & Micrometer Reticules Infinity Corrected Optics Phase Contrast, Polarising, Fluorescence & Dark Field Kits Quintuple Nosepiece Application-specific Objectives & Eyepieces Digital Cameras (3MP, 9MP, 10MP, 14MP) with Adaptors Battery Backup (6–7 Hours) Wooden Storage Box
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is DIGITAL MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
