AJKANT Cathetometer L-Shaped (Model: AJK-EDEQ-5575)

Product Overview & Key Applications

The Cathetometer L-Shaped from AJKANT Overseas is a precision optical laboratory instrument used for measuring small vertical distances and determining the difference in height between points with high accuracy. Its L-shaped construction provides a stable arrangement for optical observation and precise measurement. The instrument is commonly used in physics laboratories for experiments involving surface tension, capillary action, liquid-level differences, refractive index, and other measurements requiring accurate vertical displacement . Moreover, it is suitable for educational demonstrations as well as advanced laboratory practicals. High Stability: Robust cast iron frame with levelling screws for precise alignment Scales & Verniers: Stainless steel construction for durability and accuracy Optics: Fine achromatic lenses for clear and sharp readings Dual Orientation: Usable in both vertical and horizontal planes Vertical Guide Bar: Made of gun-metal, rotates on ball centers with bearings, and can be clamped at any position Measuring Range: Available in 50 cm or 100 cm models   Measuring Range 0 to 50cm and 100cm Length of Scale 103mm Magnification of Telescope 10x Visual Distance 100cm to infinity Graduation 0.5mm in division Cathetometer for Physics Experiments A cathetometer allows users to determine vertical distances between two points by making precise optical observations. Therefore, it is particularly useful when direct measurement is difficult or when a small difference in height needs to be determined accurately. The L-shaped arrangement provides a practical configuration for positioning the optical system and measurement mechanism. As a result, students can use the instrument to understand precision measurement techniques while performing laboratory experiments. Applications of L-Shaped Cathetometer The Cathetometer L-Shaped can be used in physics and related scientific laboratories for experiments requiring accurate vertical displacement measurements. Typical educational applications include determining differences in liquid levels, studying capillary phenomena, measuring small height differences, and supporting optical measurement experiments. Furthermore, it can be used in demonstrations where students need to understand the relationship between an observed optical position and an accurately measured vertical distance. Educational and Laboratory Benefits The instrument helps students develop practical skills in precision measurement, optical alignment, observation, and experimental recording . In addition, it encourages careful positioning and repeated observations, which are important parts of quantitative laboratory work. Teachers can introduce the instrument during physics practicals and explain how small vertical differences can be measured using an optical arrangement. Consequently, students gain a better understanding of measurement accuracy and experimental technique. Suitable for Schools and Research Laboratories The Cathetometer L-Shaped is suitable for schools with advanced physics laboratories, colleges, universities, research institutions, and scientific teaching facilities. It can support both instructional demonstrations and appropriate laboratory experiments. AJKANT Overseas supplies laboratory equipment for educational and scientific applications, providing institutions with practical instruments for physics experimentation and measurement.

Technical Specifications

Frequently Asked Questions (FAQ)
