Product Overview & Key Applications
Collimating Tube : Brass pipe construction, O.D. 50 mm, I.D. 44 mm. Fitted with circular type optically ground slit and Holfmann’s diaphragm . Rack & pinion arrangement for smooth focusing. Telescope Tube : Brass pipe, O.D. 50 mm, I.D. 44 mm. Rack & pinion focusing for accurate spectral line observation. Eyepiece : Ramsden type, 10× magnification, with conical pointer in the focal plane. Optics : Corrected achromatic doublets fitted in lens holders of both collimator and telescope. Doublet: Diameter 44 mm, Focal Length 350 mm (14″). Prism Table : Mounted on a machined cast iron plate, actuated by tangent screw for smooth rotation. Sufficient gap provided between collimator lens and prism table to accommodate Fabry–Perot Etalon for high-resolution studies. Aluminium casting cover with dual gates (incident & emergent light paths). Calibration : Drum calibrated for the visible spectrum (4000 Å – 7000 Å) . Accuracy: ±5 Å. Mechanical Construction : Collimator, telescope, prism table, and drum assembly mounted on a rigid cast iron base. Base painted staple grey , optical assemblies painted black . Total Weight: 20 kg for stable, vibration-free operation.
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is Zeeman Effect compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
