Product Overview & Key Applications
Optical System: Infinity optical system. Stand: Sturdy, single-mould aluminium die-cast stand with anti-rust protection. Viewing Head: Siedentopf trinocular head, 30° inclined, 360° rotatable, interpupillary distance (IPD) 48–75 mm, with diopter adjustment. Eye Guards: Adjustable rubber eye guards for viewing comfort. Eyepieces: Wide-field 10x eyepieces, F.O.V 20 mm, with ±5 diopter adjustment, anti-fungal and anti-reflective coated. Nosepiece: Inward-facing quintuple revolving nosepiece with coded feature, click-stop mechanism, and rubber grip. Objectives: Infinity plan objectives – 4x/0.10, 10x/0.25, 40x/0.65 (SL), 100x/1.25 oil (SL). Magnification Range: 40x to 1000x. Mechanical Stage: Double-plate graduated stage (150 mm × 139 mm), X/Y travel 75 mm × 52 mm, rackless, scratch-resistant, with dual specimen holder clips. Focusing: Coaxial coarse and fine focusing, fine adjustment scale value 0.002 mm. Condenser: Movable Abbe condenser, N.A. 1.25, anti-fungal and anti-reflective with aspheric lens; iris diaphragm with frosted white/blue filter. Illumination: 3.5 W LED (up to 100,000 hours) with intensity controller. Display: LCD display for magnification, sleep mode, brightness indication, lock, and more. Power Supply: Universal input 110–240 V with integrated voltage stabilizer. Packaging: Inner thermocol/styrofoam with outer cardboard box for secure packing. Applications: The Research Trinocular Microscope, when integrated with iPad connectivity, expands research and teaching potential. A demonstration video is available on YouTube showcasing its features and applications.
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is RESEARCH TRINOCULAR MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
