RESEARCH TRINOCULAR MICROSCOPE | Manufacturer

Product Overview & Key Applications

Optical System: Finite optical system. Stand: One-piece robust aluminium die-cast body with anti-rust finish. Viewing Head: Siedentopf trinocular head, 30° inclined, 360° rotatable; interpupillary distance 48–75 mm with diopter adjustment. Eye Guards: Flexible, adjustable rubber eye guards for enhanced comfort. Eyepieces: Widefield 10x, F.O.V. 18 mm; optional 10x, F.O.V. 20 mm; antifungal and anti-reflection coated. Nosepiece: Forward-facing quadruple revolving nosepiece with precise click-stop mechanism and rubber grip. Magnification Range: 40x to 1000x. Objectives: Plan achromatic 4x/0.10, 10x/0.25, 40x/0.65 (spring-loaded), 100x/1.25 oil (spring-loaded). Mechanical Stage: Double-plate graduated stage, 140 mm × 140 mm; X/Y travel range 90 mm × 65 mm; scratch-resistant surface with dual specimen holder clips. Focusing: Coaxial coarse and fine focusing system with fine adjustment sensitivity of 0.2 mm/rotation. Condenser: Movable Abbe condenser, N.A. 1.25 with aspheric lens; iris diaphragm with frosted white/blue filter; antifungal and anti-reflection coated. Illumination: 3W LED light source (up to 100,000 working hours) with adjustable brightness control. Power Supply: Universal input 110–240V AC with integrated voltage stabilizer. Packaging: Secured with inner thermocol/styrofoam and outer cardboard box for safe transport.

Technical Specifications

Manufacturer / Brand	AJKANT Overseas
Optical System	Finite optical system.
Stand	One-piece robust aluminium die-cast body with anti-rust finish.
Viewing Head	Siedentopf trinocular head, 30° inclined, 360° rotatable; interpupillary distance 48–75 mm with diopter adjustment.
Eye Guards	Flexible, adjustable rubber eye guards for enhanced comfort.
Eyepieces	Widefield 10x, F.O.V. 18 mm; optional 10x, F.O.V. 20 mm; antifungal and anti-reflection coated.
Nosepiece	Forward-facing quadruple revolving nosepiece with precise click-stop mechanism and rubber grip.
Magnification Range	40x to 1000x.
Objectives	Plan achromatic 4x/0.10, 10x/0.25, 40x/0.65 (spring-loaded), 100x/1.25 oil (spring-loaded).
Focusing	Coaxial coarse and fine focusing system with fine adjustment sensitivity of 0.2 mm/rotation.
Illumination	3W LED light source (up to 100,000 working hours) with adjustable brightness control.
Power Supply	Universal input 110–240V AC with integrated voltage stabilizer.
Packaging	Secured with inner thermocol/styrofoam and outer cardboard box for safe transport.
Quality Compliance	ISO 9001:2015 Certified
Warranty	1 Year Manufacturer Warranty

Frequently Asked Questions (FAQ)

Q1: Is RESEARCH TRINOCULAR MICROSCOPE compliant with international laboratory standards?

Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.

Q2: What are the international shipping and export packaging terms?

We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.

Q3: How can I place a bulk order or request OEM customization?

You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.

AJKANT Overseas — Quality & B2B Export Guarantee

High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.

AJKANT RESEARCH TRINOCULAR MICROSCOPE (Model: AJK-MICR-6250)
