Product Overview & Key Applications
Optical System: High-contrast infinity-corrected optical system. Observation Head: Binocular or trinocular head, 30° inclined; interpupillary distance 48–75 mm with diopter adjustment. Nosepiece: Inward-facing quadruple or quintuple ball-bearing type revolving nosepiece with precise click-stop mechanism. Eyepieces: Wide-field 10x eyepiece, 22 mm F.O.V; antifungal and anti-reflection hard coated. Mechanical Stage: Rackless, scratch-resistant double-plate stage (180 mm × 160 mm); X/Y travel range 75 mm × 50 mm; 0.1 mm division; low-drive right-hand movement controls; coated surface for scratch protection; dual specimen holder clips. Objectives: High-contrast, infinity-corrected IQVST series semi-plan objectives: 4x (N.A. 0.10, W.D. 25 mm) 10x (N.A. 0.25, W.D. 6.7 mm) 40x (SL, N.A. 0.65, W.D. 0.6 mm) 100x (SL, oil, N.A. 1.25, W.D. 0.17 mm) All antifungal and anti-reflection hard coated. Condenser: Abbe condenser, N.A. 1.25 with aspheric lens; iris diaphragm with frosted white filter; antifungal and anti-reflection coated; rack and pinion movement on stainless steel guides. Focusing Control: Coaxial coarse and fine focusing with gear system for smooth operation; fine adjustment 0.2 mm/rotation with 2 μm precision. Illumination: Q-LED 3.5 W, 3 V with variable intensity control; up to 100,000 hours LED life. Electronics: Köhler system; universal input 110–240 V AC. Certifications: BIS (ISI), ISO 9001, USFDA, EU CE. Optional Attachments: Monocular head QVSTi series DIN infinity plan objectives 20x, 60x; wide-field 15x, 20x Pointers, micrometer reticules Phase contrast, polarizing, fluorescence, and dark-field attachments Digital USB cameras (5MP, 10MP) with built-in adaptors Halogen illumination system 6V 20W
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is RESEARCH TRINOCULAR MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
