Product Overview & Key Applications
Optical & Mechanical Specifications Optical System: Parallel zoom apochromatic optical system. Zoom Ratio: 1:18. Magnification Range: 7.5× – 135×. Observation Functions Bright Field (BF) Fluorescence (FL) Polarized Light (PL) Oblique Light (OL) Head Configuration Trinocular Head: 20° inclined, light split E100:P0 / E0:P100 Optional Head: Tilting trinocular head (0°–30° inclination), light split E100:P0 / E50:P50 Illumination Support Cold light power supply Optical fiber Coaxial episcopic illuminator Eyepiece WF10x/23 mm, diopter adjustable, paired. Objective Plan APO 1.0x, numerical aperture 0.15, working distance 60 mm. Focusing Mechanism Manual coarse focus with ±90 mm range. Stand LED 3D lighting base with built-in OCC illumination. Coaxial Illumination Supports cold light power supply, optical fiber, and coaxial episcopic illuminator. Optional Epi-Fluorescent Attachment 6-hole turret illumination system Fluorescent incident illuminator Light shading plate 4-band LED fluorescence light sources with control box 1/4λ plate Bright field cube Packaging Inner thermocol/styrofoam protection with outer cardboard box.
Technical Specifications
Frequently Asked Questions (FAQ)
Q1: Is STEREO ZOOM MICROSCOPE compliant with international laboratory standards?
Yes, all laboratory instruments supplied by AJKANT Overseas are precision-tested and calibrated under ISO 9001 quality guidelines to ensure high accuracy in research and industrial environments.
Q2: What are the international shipping and export packaging terms?
We provide comprehensive B2B export packaging (heavy-duty wooden crates/shockproof foam cartons) and complete customs documentation for worldwide delivery via air or ocean freight.
Q3: How can I place a bulk order or request OEM customization?
You can click the Contact Us button or submit an inquiry with your custom specifications to receive an official proforma quote from our export support desk.
AJKANT Overseas — Quality & B2B Export Guarantee
High-precision manufacturing, ISO 9001 compliance, custom OEM specifications, shockproof export packaging, and reliable global B2B shipment.
