LABORATORY AUTOCLAVE (VERTICAL)
Vertical autoclave units are available with chamber volumes of 22 liters to 175 liters that accommodate two and three drums accordingly. These systems are designed for meeting effective sterilization requirements in bacteriological and research laboratories, hospitals and clinics and food and beverage units. The vertical chamber design maximizes space utilization, while microprocessor control system enables comfortable working all the time you operate the machine.
Salient Features
- Indicator light indicates working state
- Over temperature & pressure auto-protection
- Double scale indication pressure gauge
- Autoclave / Sterilizer
- Radial Locking, Safety Valve, Low Water Indicator, Pressure Interlock
- Power Supply
- AC 220 Volts/ 50 Hz
- Internal Tank Capacity
- 22 Ltr
- 40 Ltr
- 50 Ltr
- 95 Ltr
- 175 Ltr
- Working Pressure
- 1.2 kgf/cm sq.g (15 psi-17 psi) (can be upgraded to 30 psi)
Technical Specifications & Models
| Model No. | AJK-VAN-1 | AJK-VAN-2 | AJK-VAN-3 | AJK-VAN-4 | AJK-VAN-5 |
|---|---|---|---|---|---|
| Internal Tank Capacity | 22 Ltr | 40 Ltr | 50 Ltr | 95 Ltr | 175 Ltr |
| Chamber Dimensions | 10" x 18" | 12" x 22" | 14" x 22" | 18" x 24" | 22" x 36" |
| Working Pressure | 1.2 kgf/cm sq.g (15 psi-17 psi) (can be upgraded to 30 psi) | ||||
| No. of Drums & Sizes | - | 2 (9" x 11") | 2 (9" x 11") | 2 (12" x 15") | 2 (12" x 15") |
| Sterilsation Time | 25 to 30 Minutes | ||||
| Digital Timer | 0 to 99 Minutes | ||||
| Outer Chamber | Mild Steel (304 Grade Stainless Steel Optional) | ||||
| Inner Chamber | 304 Grade Stainless Steel (316 Grade Optional) | ||||
| Safety Features | Radial Locking, Safety Valve, Low Water Indicator, Pressure Interlock | ||||
| Door Locking Type | Radial Type (Wing Nut Optional) | ||||
| Power Supply | AC 220 Volts/ 50 Hz | ||||
| Optional Accessories | PID Controller, Digital Alarm, Dot Matrix Printer, NABL Certification, Chart Recorder | ||||
Need Bulk Export Pricing or Tender Quote?
We manufacture and export custom-configured laboratory setups with ISO 9001:2015 certification and seaworthy packaging.
Request B2B Export QuoteFrequently Asked Questions
Yes, the LABORATORY AUTOCLAVE is manufactured by AJKANT Overseas under ISO 9001:2015 certified quality systems and carries CE declaration of conformity for global institutional export.
Standard units operate on AC 220V–240V / 50Hz. For North American and international export orders requiring 110V–120V / 60Hz power, custom configurations are available upon request.
Every LABORATORY AUTOCLAVE is wrapped in shockproof bubble insulation, moisture-absorbing silica pouches, heat-sealed polythene vapor barriers, and secured inside ISPM-15 fumigated seaworthy wooden crates.
AJKANT Overseas provides a 1-year comprehensive standard warranty on the LABORATORY AUTOCLAVE. Factory replacement parts, heating elements, sensors, and technical guidance are readily supplied.
The listed price serves as a B2B market benchmark. For customized specifications, university project discounts, or tender paperwork, click 'Request B2B Export Quote' or contact export@ajkantoverseas.com.
